FEATURES
- BRIDGED 12" ENGINEERED I-BEAM (19 LBS/FT)
- NECKBOSS 12" ENGINEERED I-BEAM
- DIAMOND MESH WIRE FLOOR STORAGE
- WELD ON SPARE TIRE MOUNT
- 2" X 6" 11GA. TUBING BED FRAME
- STRAIGHT DECK
- RAMP POCKETS W/8' LONG HEAVY DUTY SLIDE IN 4" CHANNEL RAMPS
- SLIDE IN SIDE STEP ON BOTH SIDES
- CHAIN RACK & STORAGE BOX / WINCH READY
- MEGA LOCKABLE TOOLBOX
- ADJUSTABLE 2-5/16" GN COUPLER (30,000 LBS)
- 2 SIDE WIND SPRING LOADED DROP JACK LEGS (12,000 LBS)
HEIGHT
2'10"
WIDTH
8'6"
DECK LENGTH
24'
LIVING QUARTERS
0
-
DRY WEIGHT
7130 lbs
-
AXLES
10000 lbs
Exterior
STEEL
Frame
STEEL
Floor
STEEL
